Titan 3,500 lb Sliding Bridge Jack
$1,571.91
SKU
TTN*SJ-35
The Titan SJ-35 is a scissor style hydraulic sliding bridge jack with a 3,500 lb. capacity. (For use with the SDPL series 4-post lifts)
The Titan 3,500 lb. capacity sliding bridge jacks can be added to either of the 7,000 lb. capacity Titan parking lifts to assist in lifting the front or back of a vehicle off the runways for wheel and suspension work. This scissor style hydraulic jack comes complete with rubber pads, stackable height adapters, and telescoping arms that allow the jack to slide between the two runways.
Height Adapters
- Short - 1.25"
- Long - 5"
- Stacked - 6.25"
Dimensions
| Lowered Height | 2-5/8" |
|---|---|
| Maximum Lifting Height | 15-1/2" |
| Minimum Pad Width | 35-1/4" (out to out) |
| Maximum Pad Width | 65" (out to out) |
| Sliding Base Minimum Width | 32-3/4" (out to out) |
| Sliding Base Maximum Width | 55-1/2" (out to out) |
Shipping Info
| Shipping Length | 38" |
|---|---|
| Shipping Width | 23" |
| Shipping Height | 15" |
| Shipping Weight | 350 lb |
| Shipping Length | 38 |
|---|---|
| Shipping Width | 23 |
| Shipping Height | 15 |
| Warranty | 5 Year Structural / 1 Year Parts |
