A Texas style two post lift with 15,000 lb. lifting capacity, large twin 3” cylinders with low friction chain rollers, and a “big foot” base plate for extra stability.
The Titan 15,000 LB 2 Post lifts are commercial grade and ideal for automotive service shops or auto enthusiasts. They come with a 220 Volt power unit easily adaptable to most commercial applications. These lifts have the heavy-duty leaf chain, the steel pulleys, the high-strength cable equalization system and everything you'd expect from a quality lift. They come in a durable scratch resistant Cobalt Blue powder-coated finish with bright yellow arms for safety.
The Titan 15,000 LB 2 Post above ground lifts should be installed on a concrete floor with a minimum thickness of 6 inches and 3,000 PSI strength. These rugged and versatile lifts are engineered and manufactured to the highest quality standards to provide you years of trouble free service.
Features
- 15,000 lb. lifting capacity
- Low profile automatic arm restraints
- Dual 3” diameter cylinders with low friction chain rollers
- “Big Foot” base plates for stability
- Electrical override automatic safety shut-off on clear-floor models
- FREE mounting hardware
- Durable powder-coated finish
- 1 Year Electric/Hydraulic Warranty
- 5 Year Structural Warranty
SPECIFICATIONS
| Overall Height | 182" |
|---|---|
| Overall Width | 148.375" |
| Width Between Post | 120.75" |
| Drive-Thru | 109.5" |
| Min Pad Height | 5" |
| Max Pad Height | 76.5" |
| Lifting Speed | 45 sec |
| Lifting Capacity | 15,000 lb |
| Concrete Spec Min | 6" @ 3,000 PSI |
| Power Unit | 220V-1PH-60HZ-20AMP |
SHIPPING
| Shipping Length | 126" |
|---|---|
| Shipping Width | 36" |
| Shipping Height | 53" |
| Shipping Weight | 2,650 lb |
| Shipping Length | 126 |
|---|---|
| Shipping Width | 35 |
| Shipping Height | 50 |
| Warranty | 5 Year Structural / 1 Year Parts |
