Titan HD4P-12000 4-Post Lift
$7,639.00
SKU
TTN*HD4P-12000
The Titan HD4P-12000 is a heavy duty 4-post lift with a 12,000 lb lifting capacity. This commercial grade, cable driven lift gives you the power needed to work on heavy vehicles in a solid 4-post setup.
The HD4P-12000 4-post lift provides 12,000 lb of lifting capacity. There is no power beam; the cylinder is stored under one of the single-piece diamond-plate tracks. The HD4P-12000 utilizes a simple lever release system and safety locks. This commercial grade, cable driven lift gives you the power needed to work on heavy vehicles in a solid 4-post setup.
SPECIFICATIONS
| Overall Height | 88" |
|---|---|
| Overall Width | 137" |
| Overall Length | 195.25" |
| Lifting Speed | 51 sec |
| Max Lifting Height | 67" |
| Lowered Runway Height | 6" |
| Width Between Columns | 118.5" |
| Max Drive-Thru Clearance | 104.5" |
| Max Clearance Under Runway | 63" |
| Runway Width | 19.25" |
| Width Between Runways | 48" |
| Runway Length (no ramp) | 191.25" |
| Ramp Length | 38" |
| Load Capacity | 12,000 lb |
| Concrete Spec. Min. | 4" Reinforced @ 3,000 PSI |
| Power Supply | 220V-1PH-60HZ-20AMP |
Shipping Info
| Shipping Length | 196" |
|---|---|
| Shipping Width | 25" |
| Shipping Height | 43" |
| Shipping Weight | 2,320 lb |
| Shipping Length | 196 |
|---|---|
| Shipping Width | 25 |
| Shipping Height | 43 |
